Brand Name : | DIBIAO |
Model Number : | HQ |
Price : | negotiate |
Payment Terms : | T/T, L/C, west union, moneygram |
Supply Ability : | 600-800 peices per day |
Delivery Time : | 1-3days |
Certification : | CE |
High Dencity HQ PP Blue PLSATIC CORE TRAY For 65mm Rock 65mm
“DIBIAO” brand- Q series core tray is designed according to
standard wire-line rock core, its model include BQ.NQ.HQ.PQ,and we
also have lid, block and tag as accessories to perfect drilling
work. All our goods are produced by large injection machine, and
A.B.C grade are separated according to different raw material, so
client can choose the suitable core tray. Triangle support on the
bottom to Strengthen box’s load capacity. Two lines of 7mm width
drainage hole on the end to make sure mud flows smoothly. Block is
inserted inside core tray to tell different rock core apart.Paper
tag on the top end to remark core information.30 pieces of core
trays can be stacked tightly without falling down.Compare to
ordinary type, Q core tray performs excellent under quite high/low
temperature, and its age is much longer.
Parameter:
Model | Core diameter (mm) | Single channel width(mm) | Channel number | Net weight (kg) | Dimension (mm) | Grade | Raw material | Standard color | Color Optional |
BQ | 45 | 48 | 6 | 2.06-2.3 | 1070×385×50 | A | premium PP | Light yellow | yes |
B | Medium PP | Light gray | yes | ||||||
C | Recycled plastic | black | No | ||||||
NQ | 49 | 55 | 5 | 2.1-2.4 | 1070×385×55 | A | premium PP | Light yellow | yes |
B | Medium PP | Light gray | yes | ||||||
C | Recycled plastic | black | No | ||||||
HQ | 65 | 69 | 4 | 2.1-2.5 | 1070×385×70 | A | premium PP | Light yellow | yes |
B | Medium PP | Light gray | yes | ||||||
C | Recycled plastic | black | No | ||||||
PQ | 85 | 92 | 3 | 2.6-3.1 | 1070×385×93 | A | premium PP | Light yellow | yes |
B | Medium PP | Light gray | yes | ||||||
C | Recycled plastic | black | No | ||||||
Lid | ----- | ----- | ------- | 1.2 | 1070*385 | A | premium ABS | Light yellow | yes |
B | Medium ABS | Light gray | yes | ||||||
Block | --------- | -------- | -------- | ------- | BQ/NQ/HQ/PQ | A | premium ABS | Light yellow | yes |
Tag | ----- | ----- | ------- | ------ | ----- | ---- | ------ | ------- | ----- |
Packing List:
Model | Quantity | |||
Nude / 20’GP | Nude / 40’GP | Nude / 40’HQ | Pallet (1.1*1.1*2m) | |
BQ | 2150 | 4300 | 5300 | 168 |
NQ | 2150 | 4300 | 5300 | 168 |
HQ | 1380 | 2760 | 3400 | 123 |
PQ | 1200 | 2400 | 2960 | 108 |
Lid | 30 pieces into a carton | |||
Block | 2000-1000 pieces into a carton |
![]() |
